PRODUCT LINE

PRODUCT NAME	CHARACTERISTICS		COLOR	SHAPE
TRD-5	Resin Bond Type	Standard	Black	Semi Blocky
TRD-3
TRD
TRD-23

PRODUCT NAME	CHARACTERISTICS		COLOR	SHAPE
TMMK-150	Vitrified and Metal Bond Type	Cost Efficiency	Green	Irregular
TMMK-200
TMMK-220
TMMK-250				Semi Blocky
TMMK-300				Blocky
TMMD-200		Standard	Yellow	Semi Blocky
TMMD-300				Blocky
TMMD-400
TMMD-500
TMMD-600
TMMD-700
TMMD-800
TMMD-900
TMMD-1000
TMMD-200E	Electroplated Type	Standard	Yellow	Semi Blocky
TMMD-300E				Blocky
TMMD-400E
TMMD-500E

PRODUCT IMAGE	PRODUCT NAME	CHARACTERISTICS			COLOR	SHAPE
	TMMD-ND	Mined Diamond	Standard		White	Irregular

RECOMMENDED BONDING MATERIAL AND STANDARD SIZE LIST

PRODUCT NAME	BONDING MATERIAL				SIZE
PRODUCT NAME	Resin	Vit	Metal	EP	20 / 25	20 / 30	30 / 35	30 / 40	35 / 45	40 / 45	40 / 50	45 / 50	50 / 60	60 / 70	60 / 80	80 / 100	100 / 120	120 / 140	140 / 170	170 / 200	200 / 230	230 / 270	270 / 325	325 / 400	400 / 500
TRD-5	●	●													●	●	●	●	●	●	●	●	●	●	●
TRD-3	●	●													●	●	●	●	●	●	●	●	●	●	●
TRD	●	●													●	●	●	●	●	●	●	●	●	●	●
TRD-23	●														●	●	●	●	●	●	●	●	●	●	●
TMMK-150	●	●					●	●		●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMK-200	●	●													●	●	●	●	●	●	●	●	●	●	●
TMMK-220			●	●		●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMK-250			●	●		●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMK-300			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-200		●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-300			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-400			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-500			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-600			●	●	●	●	●	●	●	●	●	●	●	●
TMMD-800			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-1000			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-200E				●				●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-300E				●				●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-400E				●				●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-500E				●				●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
TMMD-ND			●	●			●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
